47
OPERATION
OPERATION
#415-R1
8-15-18 - JR
Width Distribution Report
When a production run is complete (or
anytime during a production run) the Width
Distribution report will graphically show the
distribution of the average widths of the
incoming lumber. This information can be
useful when designing another arbor to be
run with similar lumber. This report can
also be a valuable tool for verifying that
purchased lumber hasn't been pre-sorted
and picked through for particular widths.
Arbor Setup Report
The arbor setup report shows the
information necessary to set up the Opti-Rip
software and the rip saw for a particular job.
If the software is used off-line to optimize
jobs, this report can be printed and given to
the rip saw operator so that he knows how to
set the job up. On movable blade saws, the
top portion of the report shows the rip needs
while the bottom portion shows how the saw
should be set up.
