15
ENGINEERED VALVES
Stem Designs
ITEM DESCRIPTION
1 Capscrew
2 Disc Spring
3 Stop Nut
4 Stem Seal Washer
5 Stem Seal
ITEM DESCRIPTION
1 Nut
2 Disc Spring
3 Keyed Shaft
4 Stud
5 Stem Seal Washer
6 Stem Seal
3" Stem Design
1", 1.5" and 2" Stem Design
Figure 14 - 1", 1 1/2" and 2" Stem Design.
Figure 15 - 3" Stem Design.
Installation, Operation and Maintenance Manual IOM-CAM-BALL-T31
