3.4.2 Configuration
The radio control configuration to the control system located in
the fan box must take place only the first time and before starting
the fire (cold appliance).
Proceed as follows to set the radio control configuration:
Find a "tool having a tip of the correct size" and hold the
radio control, back side up, and directed towards the
appliance.
●
Connect the appliance to electrical power through a double
pole switch (a switch installed during appliance installation,
see section 2.3.10).
●
Within 5 seconds of electrical power connection, insert the
"tool having a tip of the correct size" into the small hole on
the back of the radio control until the audible signal
sounds, indicating that the configuration has been set (a
long beep).
●
In order to check that configuration has been carried out
correctly, when the appliance is cold, push the MAN button
(short beep sound): the fan should run, and by pushing buttons
1, 2, 3, 4 and 5 (a short beep sound each) the different speeds
should be activated.
Should the radio control no longer respond,
although the battery is still efficient (i.e.: leds turn on
without emitting any sound), configuration has to be
repeated.
