4.2 Routine maintenance
We recommend that the appliance and the chimney flue be thoroughly cleaned at least once a year. When the draught is too little, or
when unsuitable wood is used, a more frequent cleaning may be needed.
4.2.1 General cleaning
WARNING: All cleaning and inspection work must be done when the appliance is completely cold and disconnected
from the electrical power source (electronic control unit switch in OFF position).
Before starting regular cleaning work, remove the indicated
parts from the interior of the appliance, in the following
numerical order, being sure to take particular care in handling
the CMtech® panels (see figure 3).
For the steel elements [A] and, [B] make the movements
illustrated in figures 1 and 2 (to remove the steel elements [B]
lift the pieces laterally, bend towards the centre and remove).
You can now proceed in cleaning the appliance inner parts with
a metal brush and a vacuum cleaner; to ensure that the flow of
flue gases is not obstructed, clean up to the smoke outlet and
remove any ashes and soot accumulated on its walls during the
burning process.
In the end correctly assemble the component parts
removed in reversed sequence.
