Campbell Hausfeld IronForce IFN2190 User Manual

21
Use a pressure regulator on the compressor, with an operating
pressure of 0-125 psi. A pressure regulator is required to control the
operating pressure of the tool between 70 and 120 psi.
Loading the Nailer
1. Always connect the tool to the air supply
before loading fasteners. (fig. 9)
2. Pull nail pusher mechanism back until
pusher engages with magazine latch.
(fig. 10)
Figure
9
Figure
10 - Pusher Mechanism

Campbell Hausfeld IronForce IFN2190 Specifications

General

Brand	Campbell Hausfeld
Model	IronForce IFN2190
Category	Nail Gun
Language	English
