Campbell Hausfeld IronForce IFN2190 User Manual

22
3. Load strips of fasteners into the
magazine slot. Make sure that the
nails are placed into tool at the
proper orientation. (fig.11)
4. Squeeze the pusher and the latch together to unlatch pusher. Make
sure the head of the last nail is under the head of the pusher.
Unloading the Nailer
1. Always unload all fasteners before removing tool from service.
Unloading is the reverse of loading except always disconnect the air
hose before unloading.
2. Pull nail pusher mechanism back until pusher engages with
magazine latch.
Figure
11 - Loading fasteners

Campbell Hausfeld IronForce IFN2190 Specifications

General

Brand	Campbell Hausfeld
Model	IronForce IFN2190
Category	Nail Gun
Language	English
