Video Output Configuration

142

The resolution will be set to 1920x1080. When [ 4K/2K/MXF Setup] > [4K (4096/3840)] or [2K (2048/1920)] > [Resolution]

is set to [4096x2160], [4096x1080] or [2048x1080], you can select 2048x1080 or 1920x1080 for the output (A 145).

The camera can apply onscreen markers, zebra patterns, peaking and magnification to the MON. 1 terminal output. The camera

can apply magnification to the MON. 2 terminal output.

Depending on the signal, you can switch between the P and PsF setting (A 145, 147) for output.

Set [¢ Video Setup] (in mode) or [ 4K/2K/MXF Setup] (in mode) > [HD/SD SDI] > [Output] to [HD], [SD]

or [Off].

You can display zebra patterns on an external monitor during HD output (A 83). Zebra patterns will not be output during SD

output.

When the camera is connected via HDMI OUT terminal to an external monitor, the video signal output from the HD/SD SDI

terminal will be the same as that from the HDMI OUT terminal.

When the resolution is 2048x1080, the scan mode is PsF. When the resolution is 1920x1080, the scan mode is interlaced.

Video output will automatically switch to HD or SD, depending on the capability of the external monitor.

Set [¢ Video Setup] (in mode) or [ 4K/2K/MXF Setup] (in mode) > [SYNC OUT] > [Output] to [HD-Y] (HD

component video, luminance signal) or [Composite] (SD analog composite signal).

Video configuration

for recording

HDMI OUT

terminal

5, 8

SYNC OUT

terminal

System

priority

Recording mode Resolution Frame rate HD SD HD SD

RAW

4096×2160

3840×2160

59.94P

1080/59.94i 480/59.94P 1080/59.94i 480/59.94i29.97P

23.98P

50.00P

1080/50.00i 576/50.00P 1080/50.00i 576/50.00i

25.00P

24.00P 1080/60.00i – 1080/60.00i –

HRAW

4096×1080

3840×1080

59.94P 720/59.94P 480/59.94P 720/59.94P 480/59.94i

50.00P 720/50.00P 576/50.00P 720/50.00P 576/50.00i

12-bit

10-bit

2048×1080

1920×1080
