Synchronizing with an External Device
90
Reference Video Signal Output
You can output the camera’s video signal as a reference sync signal (analog blackburst or tri-level signal) through
the SYNC OUT terminal to synchronize an external device to this camera.
In mode, you must first set [¤ TC/UB Setup] > [Time Code]
> [24P TC/Sync] to [Normal], which is the default setting. In
mode or if the default setting has not been changed in mode, start
from step 3 below.
1 Open the [24P TC/SYNC] submenu.
[¤ TC/UB Setup] > [Time Code] > [24P TC/Sync]
2 Select [Normal] and then press SET.
3 Open the [Output] submenu.
[ 4K/2K/MXF Setup] (in mode) or [¢ Video Setup] (in
mode) > [SYNC OUT] > [Output]
4 Select [HD Sync] (tri-level signal) or [Blk Burst]* (black burst) and
then press SET.
• If necessary, select [Normal] or [XF Legacy] with the [¤ TC/UB
Setup] > [Time Code] > [24P TC/Sync] setting.
• If necessary, adjust the scan mode with the [ 4K/2K/MXF Setup]
> [SYNC OUT] > [Scan Mode] setting.
* Not available for 24.00 Hz recordings.
Synchronization signal summary
Operating modes:
Video configuration for recording SYNC OUT terminal
System
priority
Recording
mode
Resolution Frame rate
HD Sync
1
Blk Burst
Normal
2
XF Legacy
4K
RAW
4096×2160
3840×2160
59.94P
1080/29.97 (P/PsF)
1080/59.94i 480/59.94i29.97P
23.98P 1080/23.98 (P/PsF)
50.00P
1080/25.00 (P/PsF) 1080/50.00i 576/50.00i
25.00P
24.00P 1080/24.00 (P/PsF) 1080/60.00i –
HRAW
4096×1080
3840×1080
59.94P 720/59.94P 720/59.94P 480/59.94i
50.00P 720/50.00P 720/50.00P 576/50.00i
2K
12-bit
10-bit
2048×1080
1920×1080
59.94P
1080/29.97 (P/PsF)
1080/59.94i 480/59.94i29.97P
23.98P 1080/23.98 (P/PsF)
50.00P
1080/25.00 (P/PsF) 1080/50.00i 576/50.00i
25.00P
24.00P 1080/24.00 (P/PsF) 1080/60.00i –
10-bit
2048×1080
1920×1080
59.94P 720/59.94P 720/59.94P 480/59.94i
50.00P 720/50.00P 720/50.00P 576/50.00i
mode
[¤ TC/UB Setup]
[Time Code]
[24P TC/Sync]
[Normal]
mode:
[ 4K/2K/MXF Setup]
mode:
[¢ Video Setup]
[SYNC OUT]
[Output]
[Composite]
