10-17
Maintenance
9 Pull out the seal completely.
Do not pull out the seal at an angle.
If toner is adhered on the removed seal, be
careful that your hands or clothes do not
get dirty from touching the toner.
If your hands or clothes get dirty
from touching the toner, wash them
immediately in cold water. Do not use
hot water. If you do, the toner may be set
permanently.
10 Hold the toner cartridge by its
handle.
The arrows (A) on the toner cartridge should
be pointing toward the machine.
–
–
11 Insert the toner cartridge into the
machine as far as it will go.
The left edge (A) and the right side
protrusions (B, C) of the toner cartridge
should be aligned with the guides inside the
machine.
12 Push the toner cartridge to make
sure it is properly set in the
machine.
Do not touch the fixing assembly (A) as it
becomes very hot during use.
To Next Page
