Handling rolls
3. Close the Roll Feed Unit Cover .
Note
• How the printer operates after the paper is fed varies depending on the setting for automatic
detection of the remaining roll paper , as well as the barcode printed on rolls.
Automatic Detection of the
Remaining Roll Paper
Barcodes
Printer Operation After the Paper is Fed
Printed The type and amount of paper left is
automatically detected based on the barcode
printed on the roll.
There is no need to specify the type and length
of the paper .
On
Not printed Y ou must specify the type and length of the
paper . A menu for selection of the paper type
and length is automatically shown on the Display
Screen .
( → P .1 13)
( → P .1 14)
PrintedOf f
Not printed
Y ou must specify the type of paper .
( → P .1 13)
• Cut the edge of the roll if it is soiled or if there are cuts from scissors or the blade after removing
creased edges. ( → P .132 )
Handling Paper 1 19
