6
Grasp the part with the blue label in the central part
of the Spectrophotometer Carriage and move it to
the position shown in the diagram.
7
Move the White Calibration Tile Holder in the direc-
tion of the arrow and remove it from the Up-down
Unit.
Important
•
Do not touch the (a) part of the White Calibration Tile
Holder except when removing the White Calibration Tile.
Doing so may cause the White Calibration Tile to fall,
which can lead to damage.
8
Push the (a) part of the White Calibration Tile Hold-
er and remove the White Calibration Tile.
Cleaning the Spectrophotometer Unit (option) Parts
iPF6450
Basic Guide
Consumables and Maintenance Cleaning the Printer
56
