imagePROGRAF iPF8400S Service Guide
imagePROGRAF iPF8400S Service Guide September 2013
Page 12
Table 15 - imagePROGRAF iPF8400S Estimated Installation Times
Description Estimated Time
imagePROGRAF iPF8400S Main Unit (with Stand) 25 minutes
Printhead PF-05 (x2) 5 minutes
Ink Tanks (time includes installation of all eight (8) ink tanks) 25 minutes
Starting from an unpacked condition, installation times shown are the
estimated times required for installation. They are calculated based on
man-hours.
F. Installation / Service Support Tools
The tools necessary to install these printers are in the Table below.
Table 6 - imagePROGRAF iPF8400S Installation Tools
Tool Use
Hexagonal wrench (Provided with the printer
stand)
For assembling stand and removing the fixed
parts
Cut sheet paper A3 size or larger, or roll
paper
For test print after confirming printer operation
Cutter or Scissor For unpacking
In addition to the standard tools used to service this device, the following
special tools, solvents, & oils should also be carried when servicing the
imagePROGRAF iPF8400S.
Table 7 - imagePROGRAF iPF8400S Special Tools, Solvents, & Oils List
Cover Switch Tool QY9-0103-000 For pressing down cover switch
Syringe CK-0541-000 For draining ink manually
Tube QA2-6161-000 For draining ink manually
Grease PG-5000H FY9-6022-000
For applying to the places specified in the Service
Silbon paper CK-0336-000 Use for cleaning
Rubber Gloves QC1-5547-000
Use for cleaning and to prevent from dirtying the
Pen Flashlight CK-0327-000 For locking and unlocking the carriage.
1
Item Numbers and Part Numbers are subject to change due to engineering changes, etc.
