imagePROGRAF iPF8400S Service Guide
imagePROGRAF iPF8400S Service Guide September 2013
Page 14
H. Field Replacement Parts
Field replacement parts have a limited life and are expected to end during
a customer’s specific machine operations. They should be replaced as
needed by a Service Technician. Examples of field replacement parts
may include, but are not limited to the linear scale, carriage unit, etc. To
assist in the initial parts planning, the table below lists the estimated parts
life.
Note: All replacement parts shown in the tables below are for reference
purposes only and are subject to change without notice.
Table 9 - imagePROGRAF iPF8400S Field Replacement Parts List
Parts Name Part Number
1
Quantity
Estimated
Life
(A0
2
Carriage Unit
QM4-8199-000
1
25,000
Purge Unit QM3-7018-000 1
25,000
Ink Tank Supply Unit (L) QM3-9938-000 1
25,000
Ink Tank Supply Unit (R) QM3-9937-000 1
25,000
Operation Panel Unit QM3-9934-000 1
N/A
Power Supply Assembly QK1-4084-000 1
25,000
Scale, Linear QC3-1877-000 1
25,000
Main Board DIMM Ass’y
QM7-7200-000 1
25,000
Printhead (PF-05) 3872B003AA 2
N/A
Fan, Mist
QK1-1387-000
1
25,000
I. Recommended Spare Parts
In the event of a hardware failure, the following Spare Parts are recommended to
be kept in stock by the Dealer or Authorized Service Provider for replacement
purposes.
Note: All recommended spare parts shown in the table below are for reference
purposes only and are subject to change without notice.
Table 10 - imagePROGRAF iPF8400S Spare Parts List
Parts Name Part Number
1
Quantity
Carriage Unit
QM4-8199-000
1
Ink Tank Supply Unit (L) QM3-9938-000 1
Ink Tank Supply Unit (R) QM3-9937-000 1
Operation Panel Unit QM3-9934-000 1
Power Supply Assembly QK1-4084-000 1
Main Board DIMM Ass’y
QM7-7200-000 1
Printhead (PF-05) 3872B003AA 2
1
Item Numbers and Part Numbers are subject to change due to engineering changes, etc.
2
A0 Paper Size 33.1” × 46.8” (841mm × 1189mm)
