Table 14 - imagePROGRAF iPF8400S Specifications Continued
Hard Disk 2.5-inch, 250GB, 5400rpm, S-ATA I/F
Interface
Standard
Full Speed(12 Mbit/sec), High Speed (480 Mbit/sec), bulk
10BaseT/ 100BaseTX/ 1000BaseTX/ 802.3x
Option None
Print head
Ink ejection method Bubble jet method
No. of nozzles 2,560 nozzles per color
Highest Resolution Approximately 2400x1200dpi
Ink tank
Ink color Pigment ink 8 colors (MBK/BK/PC/C/PM/M/Y/GY)
Ink capacity
Packaged with a printer : 330ml, consumables : 330ml,
Ink supply method Tubing method (with sub tank)
Operation acoustic
Sound pressure level:
During standby: Approximately 35 dB (A) or less
During printing: Approximately 50 dB (A) or less
Acoustic power level:
During printing: Approximately 6.8Bels or less (coated
paper, photo/illustration mode (prior image quality),
standard mode. Measured based on printing conditions of
Operation environment
Temperature: 15 to 30°C, Humidity: 10 to 80%
(No condensation)
Power supply 100 to 240VAC (50/60Hz)
Power
consumption
During operation 190W or less
During standby
(power saving mode)
100 to120V 5W or less
220 to240V 6W or less
During power off
0.5W or less (LOT6-compliant)
Printer
dimension/weight
Printer+ stand+basket
Approximately: 74.5" (W) x 38.3" (D) x 45" (H) / Weight:
315 lb.
(Including roll holder. Ink & heads not included)
Dimension/weight
when packaged
Printer
Approximately: 82" (W) x 41.7" (D) x 33" (H) / Weight:
Stand/Basket alone
Approximately: 82" (W) x 41.7" (D) x 48" (H) / Weight:
Table 15 - Printhead PF-05
Printhead PF-05
Model PF-05
Type Bubble-jet on demand
Head configuration Six (6) colors integrated type (6 chips per print head x 2 print heads)
Nozzle pitch 1,200 dpi x 2
Nozzle per chip
MBK/BK/M/Y: 2,560 nozzles for each color
C/PC/PM/GY: 5,120 nozzles for each color
Droplet size 4 picoliters per color
Head replacement User replacement
