Clearing Staple Jams

8-59

Troubleshooting

Clearing Staple Jams

If a staple jam occurs, follow the procedure described below to remove the jammed

staples.

Finisher-S1 (Optional)

If a staple jam occurs in the optional Finisher-S1, a screen similar to the one shown

below appears on the touch panel display. Check the location of the staple jam, and

follow the procedure described below, and the procedure that appears on the touch

panel display, to remove any jammed staples.

IMPORTANT

Make sure to close all covers and drawers of the machine before clearing any staple

jams.
