Canon MVX100 - System Diagram

152
Additional
Information
E
System Diagram
(Availability differs from area to area)
* Charging with the CA-920 Compact Power Adapter or CH-910 Dual Battery
Charger/Holder (both optional)
MultiMediaCard
IFC-300PCU USB Cable
Canon printers with direct print function
PC Card Adapter
USB Reader/Writer
FD Adapter
Stereo Microphone
(commercially available)
WL-D79 Wireless
Controller
MiniDV
Video
Cassette
CG-570
Battery Charger
CA-570 Compact
Power Adapter
CA-570 Compact
Power Adapter
SC-1000 Soft
Carrying Case
BP-500 Series
Battery Pack
CB-570 Car Battery Cable
Computer
BP-500 Series
Battery Pack
WD-H37 Wide-
converter
FS-H37U
Filter Set
TL-H37 Tele-
converter
SD Memory Card
VFL-1 Video Flash Light
VL-3 Video Light
DM-50 Directional
Stereo Microphone
SS-800 Shoulder Strap
WS-20 Wrist Strap
BP-900 Series
Battery Pack*
VL-10Li Battery
Video Light
TV
VCR
S-150 S-video Cable
Digital Device
STV-250N
Stereo Video Cable
PC-A10 SCART
Adapter
CV-150F/CV-250F DV Cable
