Change the front side if the image on the front side is shifted.
2.
On the verification chart, use an accurate ruler to measure the distance that the image is shifted
in the feed direction (X) and in the direction perpendicular to the feed direction (Z).
• Measure the distance between the top-left corner on the front side and the back side in the
feed direction.
• Measure the distance for all the corners in the feed direction.
• Measure the distance for all the corners in the direction perpendicular to the feed direction.
• Calculate the average value in the feed direction (X) and the average value in the direction
perpendicular to the feed direction (Z).
3.
Enter the values according to the table below.
4.
Confirm the changed values.
5.
Print the verification chart again and verify if the media registration is optimal.
If the media registration is not optimal, change the value or use another setting depending on
how the registration looks.
Values for the Media Registration
Procedure
Settings front side What to enter
[X offset ({0})] The image is shifted in X direction (feed direc-
tion) in mm (inches).
A shift > 0 moves the image to the right-hand
side (trailing edge):
• The distance between the leading edge of
the sheet and the image on the sheet increa-
ses.
• The distance between the trailing edge of
the sheet and the image on the sheet de-
creases.
• The circles on the verification chart move to
the right-hand side (trailing edge).
A shift < 0 moves the image to the left-hand
side (leading edge):
• The distance between the leading edge of
the sheet and the image on the sheet de-
creases.
• The distance between the trailing edge of
the sheet and the image on the sheet increa-
ses.
• The circles on the verification chart move to
the left-hand side (leading edge).
4
Values for the Media Registration
Chapter 13 - Media Handling
333
