4-53
VB Administration Tools
Setting Up External Device Output
○○○○○○
To Make Settings...
1. With the Schedule Setting Tool, open the External Device Output Setting Tool.
In the Service tab of the Schedule Setting screen for a Normal or Special Schedule, check
Output1-3 in External Device Output, select a setting number and click the “Detail” button
(→ P.4-34), or click the “External device output setting tool” button on the toolbar.
If you have opened the External Device Output Tool from the toolbar, select an External
Device Output Name and setting number in the External Device Output Setting screen.
2. Check Output to External Device and set Output Time and Repetition Interval.
3. Click the “Save Settings” button to save the settings and close the External
Device Output Setting screen.
Tip
If you set Output Time at more than Repetition Interval, output continues without
interruption.
Schedule Setting Tool
