Canon VB-R11 User Manual

124
Settings for 802.1X authentication and authentication status display, and for certificate administration.
802.1X Authentication
Display the 802.1X authentication enable/disable control and status.
[802.1X Authentication]
Select this to enable or disable 802.1X authentication.
[Authentication Status]
Display the status of 802.1X authentication. There are three types of status: [Authenticated], [Unauthenticated], and [Stop].
Authentication Method
Set the authentication method used for 802.1X authentication.
[Authentication Method]
Select the authentication method used for 802.1X authentication.
[User Name]
Enter the user name used for authentication.
[Password]
Enter the required password for authentication.
This is displayed only when [Authentication Method] is set to [EAP-MD5], [EAP-TTLS], or [EAP-PEAP].
 Certificate Information
This is displayed only when [Authentication Method] is set to [EAP-TLS], [EAP-TTLS], or [EAP-PEAP].
[CA Certificate Status]
If no CA certificate is installed, [Not Installed] is displayed. If a CA certificate is installed, the validity period of the
certificate is displayed.
[Client Certificate Status]
If no client certificate is installed, [Not Installed] is displayed. If a client certificate is installed, the validity period of the
certificate is displayed.
This is displayed only when [Authentication Method] is set to [EAP-TLS].
Network Port Authentication Settings
[Security] > [802.1X]

Canon VB-R11 Specifications

General

Camera Type	Network Camera
Effective Pixels	Approx. 2.07 megapixels
Minimum Illumination	0.5 lx (Color, 1/30 sec, F2.0, AGC ON), 0.1 lx (B/W, 1/30 sec, F2.0, AGC ON)
Shutter Speed	1/30 to 1/10, 000 sec
Resolution	1920 x 1080 (Full HD)
Frame Rate	30 fps (1920 x 1080)
Sensor Type	CMOS
Image Sensor	1/3" CMOS
Aperture	F1.2 to F2.8
Angle of View	Horizontal: 90.1°, Vertical: 50.6°, Diagonal: 108.3°
Video Compression	H.264, M-JPEG
Audio Compression	G.711, G.726
Network Interface	10Base-T/100Base-TX
Protocols	TCP/IP, UDP, HTTP, FTP, SMTP, DHCP, DNS, DDNS, RTP/RTCP, RTSP, SNMP
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-10°C to 50°C
Day/Night	Auto
Power Supply	PoE (IEEE 802.3af)
Operating Humidity	20% to 80% (non-condensing)
Lens	Varifocal
