Canon VB-R11 User Manual

42
Click to switch the display language.
(2) [Setting Page]
Displays the Setting Page (P. 60).
You can make initial camera settings and settings to suit how the camera will be used.
(3) [Admin Tools]
Displays the Admin Tools top page (P. 193).
You can launch various tools for making settings, such as for using the camera, or launch a utility for managing
recorded video.
(4) [Admin Viewer]
Launches the Admin Viewer (P. 43).
(5) [VB Viewer]
Launches the VB Viewer (P. 43).
 User Authentication
When you use the Setting Page, Admin Tools or Admin Viewer, an authentication screen appears, and you are
prompted to enter a user name and password.
If you enter the wrong user name or password, you will not be able to connect to the camera. Enter the correct user
name and password and connect to the camera.
The factory default user name and password are:
User Name: root
Password: camera
The user name “root” is the administrator account for the camera.
Note
• Only administrators can connect to a camera using the Setting Page and Admin Tools.
• Authorized users with camera control privileges can also connect using Admin Viewer. You can set the user privileges of
registered users with [Security] > [User Restrictions] > [User Authority] on the Setting Page (P. 118).
Important
• To ensure system security, be sure to change the administrator password. Do not forget the new password.
• Restore factory default settings if you have forgotten the administrator password (P. 270). Note that this will reset all camera
settings to factory default settings except for date and time.
• If you connect to the camera using the administrator account, it will not be possible to connect with administrator privileges from
a different computer.
• If the administrator and an authorized user share the VB Viewer on the same computer, it is strongly recommended that the
[Remember my credentials] check box be cleared.
• The Admin Tools and the Admin Viewer cannot be used if an IPv6 address is specified. Only host names are supported for IPv6
connections.
Authentication Screen for Setting Page Authentication Screen for Admin Tools/Admin Viewer

Canon VB-R11 Specifications

General

Camera Type	Network Camera
Effective Pixels	Approx. 2.07 megapixels
Minimum Illumination	0.5 lx (Color, 1/30 sec, F2.0, AGC ON), 0.1 lx (B/W, 1/30 sec, F2.0, AGC ON)
Shutter Speed	1/30 to 1/10, 000 sec
Resolution	1920 x 1080 (Full HD)
Frame Rate	30 fps (1920 x 1080)
Sensor Type	CMOS
Image Sensor	1/3" CMOS
Aperture	F1.2 to F2.8
Angle of View	Horizontal: 90.1°, Vertical: 50.6°, Diagonal: 108.3°
Video Compression	H.264, M-JPEG
Audio Compression	G.711, G.726
Network Interface	10Base-T/100Base-TX
Protocols	TCP/IP, UDP, HTTP, FTP, SMTP, DHCP, DNS, DDNS, RTP/RTCP, RTSP, SNMP
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-10°C to 50°C
Day/Night	Auto
Power Supply	PoE (IEEE 802.3af)
Operating Humidity	20% to 80% (non-condensing)
Lens	Varifocal
