Canon XM2 User Manual

74
E
Recording
1. Set the recording program to MANUAL.
2. Press the EXP dial in.
• An arrow appears next to the shutter speed
value.
3. Pull the EXP dial up or down to increase
or decrease the shutter speed.
•You can select between 30 shutter speeds (1/6
to 1/16000) in TAPE CAMERA mode and 15
shutter speeds (1/50 to 1/700) in CARD
CAMERA mode.
• See “About the Shutter Speeds” ( 75).
4. Press the EXP dial in.
• The arrow moves next to the F number.
5. Pull the EXP dial up or down to open or close the iris.
•You can select between 19 aperture values (f/1.6 to f/8) in TAPE CAMERA mode and 17
aperture values (f/2.0 to 1/8) in CARD CAMERA mode, or close the iris completely.
• See “About the Iris” ( 75).
6. Press the EXP dial in.
• The arrow moves to the gain value.
7. Pull the EXP dial up or down to increase or decrease the gain.
• Set the gain to 0 dB, +6 dB, +12 dB or +18 dB in TAPE CAMERA mode or 0 dB, +6 dB or
+12 dB in CARD CAMERA mode.
• See “About the Gain” ( 75).
Notes:
• The shutter speed, F number and gain values will be reset if you slide the POWER switch to OFF.
If you use the standby lever, the camcorder retains your chosen values.
•A bar showing the standard exposure appears in the display.
•You can also adjust the exposure manually in the Auto, Tv and Av modes, but you have to first
lock the exposure to adjust shutter speed and iris.
EXP
shutter
speed
no
display
iris
gain
Adjusting the Exposure Manually

Canon XM2 Specifications

General

Sensor type	CMOS
Total megapixels	4.7 MP
Optical sensor size	1/4 \
Filter size	58 mm
Digital zoom	100 x
Optical zoom	20 x
Focal length range	4.2 - 84 mm
Display diagonal	2.5 \
Operating temperature (T-T)	0 - 55 °C
Minimum illumination	0.37 lx
Auto focus	Yes
PictBridge	No
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Battery life (max)	7 h

Weight and Dimensions

Depth	306 mm
Width	118 mm
Height	136 mm
Weight	1120 g
