Canon XM2 User Manual

65
E
Recording
Using the Colour Bars
You can display and record industry standard SMPTE colour bars.
1. Press the D. EFFECTS/BARS SELECT button.
• The digital effects menu appears.
2. Select COLOR BARS and press the SELECT dial in.
• The menu closes and COLOR BARS flashes in the display.
3. Press the D. EFFECTS/BARS ON/OFF button.
• The colour bars appear in the display.
• Each time you press the D.EFFECTS/BARS ON/OFF button, the colour bars are activated or
deactivated.
Activating the Colour Bars
+
CAMERA
TAPE
COLOR BARS
( 18)

Canon XM2 Specifications

General

Sensor type	CMOS
Total megapixels	4.7 MP
Optical sensor size	1/4 \
Filter size	58 mm
Digital zoom	100 x
Optical zoom	20 x
Focal length range	4.2 - 84 mm
Display diagonal	2.5 \
Operating temperature (T-T)	0 - 55 °C
Minimum illumination	0.37 lx
Auto focus	Yes
PictBridge	No
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Battery life (max)	7 h

Weight and Dimensions

Depth	306 mm
Width	118 mm
Height	136 mm
Weight	1120 g
