Canon XM2 User Manual

81
E
Recording
Using the Custom Preset
You can adjust the colour gain, colour phase, sharpness and setup level for more creative
recordings.
Adjust toward + for a deeper colour, and toward – for a lighter colour.
Adjusting the Colour Gain
Adjust toward R for a redder picture, and toward G for a greener picture.
Adjusting the Colour Phase
Adjust toward + for a sharper picture, and toward – to soften the contour.
Adjusting the Sharpness
When you adjust the custom preset functions, be sure to check the picture before you start
recording. You can save these settings under the CSTM PRESET button.
1. Open the menu and select CSTM PRESET.
• The custom preset menu appears.
2. Select the function you wish to adjust.
3. Adjust the selected function.
• See below details on each function.
• Repeat steps 2 and 3 to adjust other functions as needed.
4. Close the menu.
• The settings are saved until new changes are made.
+
,
+
CAMERA
CARD
CAMERA
TAPE
CSTM PRESET
( 18)
COLOR GAIN••
CSTM PRESET
-
+
( 18)
COLOR PHASE•
CSTM PRESET
GR
( 18)
SHARPNESS•••
CSTM PRESET
-
+
( 18)
Setting the Custom Preset Functions

Canon XM2 Specifications

General

Sensor type	CMOS
Total megapixels	4.7 MP
Optical sensor size	1/4 \
Filter size	58 mm
Digital zoom	100 x
Optical zoom	20 x
Focal length range	4.2 - 84 mm
Display diagonal	2.5 \
Operating temperature (T-T)	0 - 55 °C
Minimum illumination	0.37 lx
Auto focus	Yes
PictBridge	No
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Battery life (max)	7 h

Weight and Dimensions

Depth	306 mm
Width	118 mm
Height	136 mm
Weight	1120 g
