page 6 of 28
2.3 Construction of the Pneumatic Module
2.4 Replacing the filter
procedural method:
1. switch off the cabinet
2. remove the tubes (by pressing the unlocking ring towards the housing)
3. loosen the screws
4. replace the filter
Caution: Observe the direction of installation (arrow)!
5. reconnect the tubes, tighten the screws
6. switch on the cabinet and check that the tubes are connected tightly
