2.5 Setting of Pneumatic Components
In the pneumatic module of the endoSTORE
®
it is possible to configure pressure controller and pressure
regulator. Duration and operating phases can be adjusted in the operator software. (see chapter 4.3).
2.5.1 Factory Settings of Parameters
Parameter
ENDODRY
TM
endoSTORE® neo
discrepancy
endoSTORE® one-click
ENDODRY
TM
one-click
Drying phase 1:
0,5 bar, 20 min
0,5 bar, 30 min
Drying phase 2:
0,3 bar
0,3 bar, 60 min
Fan phase
180 min
180 min
Storage phase:
0,1 bar
0,1 bar
Pressure controller:
min. 2 bar
max. 10 bar
min. 2 bar
max. 10 bar
Pressure regulator:
SL.5
SL.5
2.5.2 Pressure regulator
The electric-pneumatic air pressure regulator regulates pressure of the particular phase.
Caution!
Attention should be paid to operation manual of the pressure regulator.
Pressure regulator
