The loudspeakers of the Reference series are equipped such that you
can connect the tweeter/midrange chassis and the woofer chassis
separately to two respective amplifiers (bi-amping), or at least via
two separate connecting cables (bi-wiring). For this purpose these
speakers are fitted with a dual terminals set. The upper pair of sock-
ets is intended for the treble/midrange frequencies, and the bottom
pair for bass frequencies. These two terminal pairs have been linked
with jumpers in the factory for normal operation with a single con-
necting cable.
Remove the jumpercables for bi-wiring operating mode and bi-amping
operating mode, otherwise the connected amplifieres might be dam-
aged. For this purpose, release the terminal screws and remove the
jumpercables.
Bi-wiring/bi-amping-terminal
Bi-wiring Bi-amping
