Canton Loudspeakers - Technical Data: Reference 9.2 DC; Driver Specifications; Cabinet and Finish Options; Performance Metrics

45
English
Designed as
High-end-compact speaker
Engineering principle
2-way-bass reflex system
Impedance
4...8 ohms
Nominal/Music Power
Handling
120/200 watts
SPL (1 W at 1 m)
87 dB
Frequency Response
25...40.000 Hz
Crossover Frequency
3.000 Hz
Woofer
180 mm (7“), aluminum
Tweeter
25 mm (1“), aluminum-ceramic-oxyd
Dimensions
9.3“ x 14.2“ x 13“
Weight
11.3 kg
Enclosure finish
Cherry veneer „Piano-finish“,
Black lacquer „Piano-finish“,
Silver lacquer „Piano-finish“,
White lacquer „Piano-finish“
Cover
Black fabric cover
Special features
DC-technology, gold-plated bi-wiring/
bi-amping terminal
Reference 9.2 DC
1
- Tweeter: 25 mm (1“)
aluminum-ceramic-oxyd
dome, vibration-damped
2
- Woofer: 180 mm (7“)
aluminum membrane with
„Wave“ surround
3
- Enclosure: 1-chamber
system
4
- Optional available
loudspeaker stand
1
2
3
4
