CanyCom CM1801 - Specifications

5
SPECIFICATIONS
– 11 –
5. SPECIFICATIONS
5.1 SPECIFICATIONS FOR THIS MACHINE
Use this product properly after understanding the specifications
for this product.
NOTE
MODEL CM1305 CM1801
MACHINE WEIGHT kg 255 260
APPLICABLE JOB AREA m
2
/h 4500 9000
O VERALL LENGTH mm 1840 1870
O VERALL WIDTH mm 995
O VERALL HEIGHT mm 885
WHEEL BASE mm 1200
TREAD mm Front 800, Rear 735
MINIMUM FREEBOARD mm 105
MODEL GH400V/GM400PV FH531V
T Y P E
Air-cooled 4-cycle gasoline
Air-cooled 4-cycle gasoline
V twin
CYLINDER mm
84
70 68 68
(BORE X STROKE)
TOTAL DISPLACEMENT cm
3
(cc) 389 (389) 494 (494)
MAXIMUM OUTPUT 9.56/4000 (13.0/4000) 13.3/3600 (18.0/3600)
STARTING SYSTEM Self-starting system
FUEL USED Gasoline
FUEL TANK CAPACITY 11
LUBRICATING OIL
1.4 1.5
CAPACITY
BATTERY TYPE V/AH 28A19R 38B19R
BATTERY CAPACITY 12/21 12/28
IGNITION SYSTEM Electronic ignition
IGNITION PLUG NO. BP4HS-10 RCJ8Y
MACHINE DIMENSIONS
kW/min
-1
(PS/rpm)
ENGINE
