CanyCom CM1801 - Greasing

7.5.2 Greasing
Grease the points as shown in the figure.
Oil to be used : page 28
4. Fulcrum of aux. speed change lever
5. Blade clutch lever fulcrum
6.&7. Fulcrum of cutter height adjusting lever link
8. Brake arm fulcrum
9. HST lever fulcrum
10. Brake pedal fulcrum
11.12.13.&14. Blade stay fulcrum
(11.12.13.&14.are also provided on the other side.)
7
– 34 –
MAINTENANCE
4.
10.
14.
5.
11.
6.
9.
13.
7.
8
12
