CanyCom CMX 227 - Shifting and Drive Control

Operation
-30-
4
1. Stop machine.
2. Move auxiliary transmission shift lever to [H
(high speed)] or [L (low speed)] position rmly.
5332M-0402-100E
Auxiliary
Transmission
Shift Lever
L
H
N
• See Specications (page 15) for the speed
range in either gear position.
• Always stop machine to shift between 2WD or AWD (all-wheel-drive) modes.
Shifting gears while machine is in motion can damage transmission.
• Use 2WD mode under normal condition.
• Pay attention to the minimum turning radius in AWD mode. In AWD mode,
minimum turning radius is greater than that in 2WD mode.
Shifting Between 2WD and AWD (CMX227 and CMX186)
• Always stop machine to shift gears. Shifting gears while machine is in motion
can damage transmission.
NOTE
• Always shift gears rmly. When transmission is not rmly shifted, it may jump
out of gear, resulting in loss of control of machine.
Shifting
