20 Instruction manual C886G, C887G & C889G Please keep this instruction manual for future reference
ADAPTING TO DIFFERENT TYPES OF GAS
TABLE 2: Adapting to different types of gas
APPLIANCE CATEGORY: I
2HS
, II
2H3+
, II
2E3B/P
, II
2HS3B/P30,50
, II
2ElwLs3B/P ,
II
2E+3+
Burner
Type of
Gas
Pressure
Nozzle
diameter
Nominal Charge Reduced Charge
mbar 1/100mm g/h l/h kW kcal/h kW kcal/h
Auxiliary
Natural
G20
20 69 — 85.7 0.90 774 0.40 344
Natural
G25
25 69 — 99.7 0.90 774 0.40 344
Natural
G25.1
25 69 — 99.6 0.90 774 0.40 344
Natural
G27
20 75 — 104.5 0.90 774 0.40 344
Natural
G2.350
13 96 — 119 0.90 774 0.40 344
Butane
G30
30 50 65 — 0.90 774 0.40 344
37 44 65 — 0.90 774 0.40 344
50 43 65 — 0.90 774 0.40 344
Semi-rapid
Natural
G20
20 97 — 179 1.88 1617 0.60 516
Natural
G25
25 97 — 208.3 1.88 1617 0.60 516
Natural
G25.1
25 97 — 208.1 1.88 1617 0.60 516
Natural
G27
20 106 — 218.5 1.88 1617 0.60 516
Natural
G2.350
13 131 — 248.8 1.88 1617 0.60 516
Butane
G30
30 68 136 — 1.88 1617 0.60 516
37 64 136 — 1.88 1617 0.60 516
50 60 136 — 1.88 1617 0.60 516
Rapid
Natural
G20
20 110 — 228 2.4 2064 0.90 774
Natural
G25
25 110 — 265.9 2.4 2064 0.90 774
Natural
25 110
—
265.7 2.4
2064 0.90 774
G25.1
Natural
G27
20 121 — 278.8 2.4 2064 0.90 774
Natural
G2.350
13 147 — 317.6 2.4 2064 0.90 774
Butane
G30
30 78 174 — 2.4 2064 0.90 774
37 72 174 — 2.4 2064 0.90 774
50 68 174 — 2.4 2064 0.90 774
Triple-ring
Natural
G25.1
25 124 — 293.4 2.65 2287 1.50 1290
Natural
G27
20 132 — 307.8 2.65 2287 1.50 1290
Natural
G2.350
13 158 — 350.6 2.65 2287 1.50 1290
Butane
G30
30 84 192.5 — 2.65 2287 1.50 1290
Natural
G2.350
37 78 192.5 — 2.65 2287 1.50 1290
Butane
G30
Natural
G20
Natural
G25
50 70 192.5 — 2.65 2287 1.50 1290
20 131 — 285.3 3.0 2287 1.50 1290
25 131 — 285.3 3.0 2287 1.50 1290
