PARTS OF THE APPLIANCE
1. Auxiliary gas burners
2. Semi-rapid burner
3. Rapid burner
4. Triple ring burner
5. Ignitor for gas burners
6. Safety device - Activates if the flame accidentally goes out (spills, drafts, etc.),
interrupting the delivery of gas to the burner.
7. Control knobs
Close-up View
1. Auxiliary Gas Burners
2. Semi-rapid burner
3. Rapid burner
4. Triple ring burner
5. Ignitor for Gas Burners
6. Flame safety Device - Activates if the flame accidentally goes out (spills, drafts, etc.),interrupting
the delivery of gas to the burner.
7. Control Knobs
Close-up View
1. Auxiliary Gas Burners
2. Semi-rapid burner
3. Rapid burner
4. Triple ring burner
5. Ignitor for Gas Burners
6. Flame safety Device - Activates if the flame accidentally goes out (spills, drafts, etc.),interrupting
the delivery of gas to the burner.
7. Control Knobs
