Instruction manual C894C 29
Please keep this instruction manual for future reference
BEFORE LOCATING THE FIXING BRACKETS
The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force
onto the controls protruding from the hob. Fix the hob on the work surface by screwing the four
brackets on the bottom of hob (see picture) after installation. Adjust the bracket position to suit for
different work surface’s thickness.
io
HOB
WORK SURFACE
A
HOB
WORK SURFACE
B
BRACKET
BRACKET
the
lace

℃
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop
after installation (see picture). This will ensure the hob is properly secured to the underside
of the work surface.
