Caple CR 9207 - Levelling the Cooker (Model CR 1207)

10
Levelling the cooker - Model CR 1207
Fig. 2.5
+ 8 mm
+ 8
0
mm
+ 35 mm
Fig. 2.6a
Fig. 2.6b
The cooker is already fitted with four
levelling feet.
Level the cooker by screwing or
unscrewing the feet (Fig. 2.5).
Make sure you follow the instructions
in Figs. 2.6a and 2.6b.
Note: bolts are supplied with the cook-
er in a separate kit.
