19
Conversion to Natural Gas or to LPG
Injectors replacement of top
burners
Every cooker is provided with a set of
injectors for the various types of gas.
Injectors not supplied can be obtained
from the After-Sales Service.
Select the injectors to be replaced accor-
ding to the table at page 21.
The nozzle diameters, expressed in hun-
dredths of a millimetre, are marked on
the body of each injector.
To replace the injectors proceed as fol-
lows:
– Remove the grids and extract the
burner bodies.
– Using a wrench, substitute the nozzle
injectors “J” (Figs. 3.4a, 3.4b, and
3.4c) with those most suitable for the
kind of gas for which it is to be used
(see “Table for the choice of the injec-
tors”).
The burners are constructed in such
a way so as not to require the regula-
tion of the primary air.
J
Fig. 3.4b
J
Fig. 3.4a
Auxiliary and
Semi-rapid
burner
Triple-ring
burner
DUAL burner
J
Injector for inner crown
J
Injectors for
outer crowns
Fig. 3.4c
