18
Important prescriptions for gas connection
700 mm
Rear wall
Suggested area for
gas mains connection
200 mm
Fig. 3.3a
700 mm
Rear wall
Suggested area for
gas mains connection
200 mm
Fig. 3.3b
Model CR 9207
Model CR 1207
