Instruction manual TSCH601 TSCH901 13
Please keep this instruction manual for future reference
INSTALLATION TYPE TWO
› Drill 4 holes of 6mm diameter at the bottom of the hanging cupboard.
› Fix the one way valve to the cooker hood, then install the cooker hood on the bottom of the
hanging cupboard, tighten the hood with the enclosed 4 screws supplied.
NOTE:
The ducting is an optional accessory, it is not supplied.
Remove the protection film before installation.
