SETUP AND CALIBRATION, Cont.
1. Press OFF key.
2. Press and hold calibration switch.
3. Press ON key.
Decimal Point
Location
0, 1, 2 or 3
Interval
1, 2 or 5
0=XXXX
1=XXX.X
2=XX.XX
3=X.XXX
Scale
Capacity
up to 9,999
Weighing
Units
1=lb only
2=kg only
3=lb/kg
4=kg/lb
5=oz only
6=g only
Calibration
Weight
Press HOLD/REL twice to
bypass or once and enter
test weight value and load
scale. Press HOLD/REL again
Remove
Test Weights
Zero Tracking
Range
.5,1,2,3,4,5,
6,7,8 or 9
4% Zero
Tracking Limit
Yes/No
Power Up
Zero
int=
dP=
CAP=
Unt=
Lod=
UnLd
trA=
trL=
PU0=
FLt=
F=
br=
UnS=
Sr=
ASH=
SLP=
Pbt=
HLd=
nrU=
Filtering?
0, 1, 2 or 3
0=No Filtering
1=Minimal Filtering
2=Moderate Filtering
3=Custom Filtering
If 0, 1 or 2 then
If 3 then
Filter Level
1 to 16
Break Range
1 to 64
Motion Range
1 through 9
Sample Rate
1 to 12
Auto Shutoff
0=Disable or
1 to 9 minutes
Sleep Mode
0=Disable
1 to 9 minutes
Push Button
Tare?
Yes/No
Enable Hold
Feature
Yes/No
Enable
Non-Roll-Up
Mode
Yes/No
CALIBRATION COMPLETE
(skipped if
FLt= 1 or 2)
iSnd=
Inhibit
Serial Data
No
Figure No. 6
