0044-M078-O1
v
6027 and 6029
Page 2
UNPACKING INSTRUCTIONS
v
Remove scale from carton by lifting up with equal force from column and platform base of
the scale.
v
Inspect the scale for any signs of damage due to shipping, such as exterior dents and
scratches. It is the responsibility of the Purchaser to file all claims for any damages or loss
in transit incurred. Retain packing and shipping carton for return of scale if necessary.
v
Remove all plastic wrapping, foam ¿llers and cardboard material from the scale.
v
Remove and unpack the power supply and cord, if the scale was ordered with this option.
CARE AND CLEANING OF SCALE
v
DO NOT subject the platform to sudden shocks.
v
DO NOT spray water directly on the display head.
v
DO avoid areas where the scale might be exposed to moisture.
v
DO NOT use abrasive cleaners on this instrument.
v
DO NOT use acetone or other volatile solvents for cleaning.
v
DO clean the scale using a damp soft cloth and mild detergent.
INSTALLATION
Power Supply
To power the weight indicator without batteries, connect the 12 VDC, 1 Amp power supply’s
connector into the power jack on the lower back of the indicator and then plug the power
supply into the proper electrical outlet. See Figure 1. On models requiring 220 VAC, it is the
customer’s responsibility to obtain the correct power adapter plug. The scale is now ready for
operation.
NOTE! The power supply is also used to recharge the batteries, when
the weight indicator is operated from Ni-Cad or NiMH batteries.
Scale
Cable
Figure No. 1
Battery
Cover
Power
Su
