4.2 LED INDICATOR FUNCTIONS
The following describes the functions of each of the LED indicators and
associated legends contained on the face of the instrument display.
NET
The NET indicator shows the weight displayed is the net weight. Net weight is
determined by subtracting the stored tare weight from the gross or scale weight. The tare
weight, usually the weight of the empty container, is entered using the tare operation key.
Note that the NET indicator is only active when the display is in the weight mode as
shown by the illumination of either the lb or lb-oz indicator.
TARE
The TARE indicator shows that the scale is in a weight mode in which a known tare
(container) weight may be keyed in via the numeric keypad, or in a mode that will display
the current TARE weight.
lb
The lb indicator shows that the display is in the weight mode and that the weight
displayed is in decimal pounds.
lb-oz
The lb-oz indicator shows that the display is in the weight mode and the weight displayed
is in pounds and ounces.
MOTION
The MOTION indicator shows that the scale weight is unstable. An unstable weight
reading may be caused by motion on the scale platform. The ZERO and PRINT/XMIT
functions are disabled while the MOTION indicator is illuminated.
ZERO
The ZERO indicator is active during any mode and is used to indicate that the scale
gross weight is within ± 1/4 of a graduation of true zero.
SAMPLE
The SAMPLE indicator shows that the display is in the sample mode and that the value
shown is the sample quantity requested in pieces.
MOTION
ZERO
lb
GROSS NET
lb - oz
SAMPLE
TARE
COUNT
WT/PC PC/WT
