Cod. +030220151 - Rel. 2.1 - 04/09/98
34
WIRING DIAGRAMS
Wiring diagram for multiple units:
4
5
TRF
IR32
4
5
IR32
4
5
IR32
TRF
TRF
INS
4
5
IR32
TRF
TRF
INS
MAIN
SER
MAIN
= mains power supply
TRF
= transformer
INS TRF
= insulating transformer
=earth
SER
= multiple connection to the control system.
IR32 panel mounting connections:
34
36
