Cod. +030220151 - Rel. 2.1 - 04/09/98

IR32 DIMENSIONS

IR32M, IR32S,

IR32P

IR32Y

IR32C

A 75 75

B 33 33

C 64 72

D 64 64

IRDR and S90RDPW2

S90OEM4PWR

IR32

Default Chapter1
- Table of Contents1
General Features2
- Models Available2
- Main Features of the Infrared Series3
Front Panel and Buttons5
- LED Display - Indicators5
- Keypad6
Installation7
- Standard Configuration7
- Cautions8
- Selection of the Main Working Parameters - Other Important Parameters9
List of the Working Parameters to be Checked before Starting the Unit10
How to Modify the Working Parameters11
- Gaining Access - How to Modify the Parameters11
- How to Exit the Procedure - How to Exit the Procedure Without Memorizing the Modified Data11
Reset Procedure12
Remote Control Unit13
- Technical Specifications - Keypad Description13
- Buttons Used to Activate/Deactivate the Use of the Remote Control Unit13
- Buttons Used to Modify the Main Parameters (Directly Accessible Buttons)14
- Buttons for the Remote Control of the IR Instruments14
How to Use the Remote Control Unit14
- Access Without Code14
- Access with Code15
Further Information16
- Configuration Parameters - the Password16
- Parameters for the Management of the Temperature Sensors17
- R = Parameters for the Temperature Regulation19
- C = Parameters for the Compressor Management20
- D = Parameters for the Defrost Management22
- A = Parameters for the Alarm Control25
- F = Parameters for Controlling Evaporator Fans29
Summary Diagram of the Evaporator Fan Operation30
Notes for the New Release32
Wiring Diagrams35
- Wiring Diagram for Multiple Units - IR32 Panel Mounting Connections35
Operating States of the Equipment39
- Sequence of Main Phases39
Alarms and Troubleshooting40
- What to Do if the IR32S, IRDRSE/S0 Fails to Work42
- What to Do if the IR32Y Fails to Work42
- What to Do if the IR32P or IR32C, IRDRC Fails to Work44
Technical Characteristics45
Temperature/Resistance Ratios for NTC Thermistors49
IR32 Dimensions51
Code Numbers for Ordering Controls and Accessories52
IR96: Microprocessor-Based Freezer Controller54
New Functions54
Technical Features - - Connections56
Ir96: Keys Functioning57
Functioning57
IR96: Parameters59
- Parameters Modification59
- New-Set Values Memorisation59
List of Parameters60
Description of Particular Parameters and Performances62
- Memorisation of Minimum/Maximum Temperature62
- Functioning of the Relay 462
- Type of Sensor - Digital Inputs Configuration62
IR96: Alarms63
Dimensions63
