TECHNICAL CHARACTERISTICS
Models IR32M IR32S IRDRS0 IRDRSE IR32Y IR32P IR32C IRDRC
Power supply:
Wide range: 12-24Vac/dc, ±10%, 50/60Hz
Universal: 24-240Vac/dc, ±10%, 50/60Hz
24 Vac e 220 Vac on power board
•
12-24 Vac/dc
110-240 Vac/dc
(mod. IR32S*H)
•
230
•
•
• •
Consumption
2VA 2VA 3VA 3VA 2VA 2VA/3VA 3VA 3VA
Accuracy:
NTC Carel
±1°C
PTC
±3°C ±3°C ±3°C ±3°C ±3°C
Type of sensor used for control:
NTC Carel (10 KΩ a 25°C): standard ON
PTC 985 Ohms a 25 º C, upon request:
•
•
•
•
• • •
•
•
•
•
•
•
Type of sensor used for defrosting:
NTC Carel (10 KΩ a 25°C), standard ON:
PTC 985 Ohms a 25 ºC, upon request:
•
•
•
•
•
•
•
Range of operation: -40÷90°C (-40÷130 °C with PTC)
• • • • •
Operating conditions: 0÷60°C, with relative humidity less than 80%rH
• •
0÷50 °C
(mod. IR32S*H)
• • • • • •
Storage conditions: -25÷70°C, with relative humidity less than 80%rH
• • • • • • • •
(*) 0/50°C, <80rH%, for IR32S with universal power supply
User interface
LED display with 2 and a half digits
• • • • • • • •
Signal buzzer optional ON
•
standard
• • • •
Compressor ON indicator
• • • • • • •
Defrost ON indicator
• • • • • • •
Fan ON indicator
• • •
Continuous cycle ON indicator
• • • • • • •
Particular functions
Duty setting
• • • • • • •
Continuous cycle
• • • • • • •
Multi-function input
• • • • • • • •
Multi-function output (IR32P only with S90OEM4PWR)
• • •
Serial connection
• • • • • • •
Keypad protection
• • • • • • •
Virtual sensor
• • • • •
Decimal point
• • • • • • • •
