Carel IR32C User Manual

Cod. +030220151 - Rel. 2.1 - 04/09/98
45
Models IR32M IR32S IRDRS0 IRDRSE IR32Y IR32P IR32C IRDRC
Programming
Keypad
• • • • • •
Remote commander (optional)
• • • • •
Mechanical characteristics
Dimensions:
33 x 75 x 72:
33 x 75 x 64:
• •
•
•
•
Index of protection: IP65 (front panel)
• • • • •
IP40 (front panel)
• • •
Stirrup-catch fixing:
• • • • •
Quality and accuracy
Test in circuit
• • • • •
Watch dog
• • • • •
Immunity from interference according to standards
IEC 801-2 and 801-4 level 4
• • • • • • • •
GENERAL SPECIFICATIONS (for all models)
Connection Screw terminals for cables with min. 0.5mm
2
- max. 1,5mm
2
cross-section
Classification according to protection against shock Class I
Number of automatic cycles for each automatic action (e.g.: relay) 100.000
Ageing period (operating hours) 60.000
Type of action-disconnection 1C
PTI of materials used for insulation 250 V
Period of electric stress across insulating parts Long
Environmental pollution Normal
Heat and fire resistance category D
Category (surge immunity) 1
Software class and structure Class A (EN60730-1)
Time constant 35 s in forced air
Disposal of the product avoid disposing the device in domestic rubbish. To dispose the device refer to the
environmental protection laws in force in your Country
Electrical characteristics of relays fitted in all models except the
compressor relay on board S90RDPW200
Electrical characteristics of the compressor relay fitted on board S90RDPW200
Maximum peak current: 10A Maximum peak current: 70A
Maximum operating current: 8A Maximum operating current: 20A
Maximum operating power: 2000VA Maximum operating power: 5000VA
Maximum operating resistance load at 220Vac: 1760W Maximum operating resistance load at 220Vac: 4400W
Maximum inductance load 300 W at 220Vac (cos.psi=0.7)
Maximum inductance load 1800 W at 220Vac (cos.ϕ=0.7)
Maximum operating tension: 250Vac Maximum operating tension: 250Vac
