IR96: PARAMETERS
The parameters have been organised on two levels:
FIRST LEVEL: frequent parameters. They are indicated with F in the table and the password is not
necessary to gain access to them. To modify them operate as follows:
1. press the button for more than 5 seconds (in case of alarm, first silence the buzzer);
2. the display shows the code of the first parameter to be modified.
3. To modify the parameters see the section “parameters modification”.
SECOND LEVEL: configuration parameters. They are indicated with C in the table and it is necessary to
insert the password for any modification, as indicated here below:
1. press simultaneously the buttons and for more than 5 seconds;
2. the display shows 00;
3. press the buttons and until 22 (password) is displayed;
4. confirm by pressing ;
5. the display shows the code of the first parameter to be modified.
To modify the parameters see the following section “parameters modification”.
Parameters Modification:
To modify a parameter operate as follows:
1. press and/or until the parameter to be modified is displayed (see the parameters table);
2. press the button to visualise the value associated to the parameter;
3. modify its value by pressing the buttons and/or until you reach the requested value;
4. press the button to confirm temporarily the newly set value and to go back to the parameter code
visualisation;
5. repeat all operations from the point "press and/or " to modify other parameters values;
New-Set Values Memorisation:
Press the button to memorise all newly-set values and exit the procedure.
To exit without modifying the parameters: do not press any button for at least 60 seconds ( TIME OUT exit).
Warning: if the button is not pressed after modifying operations, all effected modifications will be lost.
