Carel IR32C User Manual

Cod. +030220151 - Rel. 2.1 - 04/09/98
51
CODE NUMBERS FOR ORDERING CONTROLS AND
ACCESSORIES
NTC Sensors
Description Operating range Index of protection Code
NTC, bulb 6x15mm -50÷50°C IP67 NTC0**HP00
NTC, bulb 6x40mm -50÷100°C IP67 NTC0**W*00
NTC for insertion -50÷110°C IP67 NTCINF0600
NTC for wall mounting -10÷70°C IP30 ASWT011000
NTC for duct mounting -10÷70°C IP55 (*) ASDT011000
NTC for wall mounting
(temperature + humidity)
0÷50°C / 10÷90% rH IP30 ASWC111000
NTC for duct mounting
(temperature + humidity)
0÷50°C / 10÷90% rH IP55 (*) ASDC111000
(*) the index of protection above mentioned refers to the case: IP40 refers to the sensor.
PTC Sensors
Description Operating range Index of protection Code
PTC, bulb 6x40, 1,5m
0÷150°C
IP65 PTC0150000
PTC, bulb 6X40, 1,5m
-50÷100°C
IP67 PTC015W000
PTC, bulb 6x180, 6m
-50÷100°C
IP67 PTC060WA00
PANEL MOUNTING THERMOMETER
Thermometer
IR32M: 2½ digits, NTC, 12-24Vac/dc IR32M0L000
Panel mounting thermostats with defrost timer
IR32S: 2½digits, 12-24Vac/dc IR32S0L000
IR32S: 2½digits, 12-24Vac/dc, for remote control, with buzzer IR32S0LBR0
IR32S: 2½digits, 24-240Vac/dc IR32S0U000
IR32S: 2½digits, 24-240Vac/dc, for remote control, with buzzer IR32S0UBR0
IR32S: 2½digits, 110-240Vac/dc IR32S0H000
IR32S: 2½digits, 110-240Vac/dc, for remote control, with buzzer IR32S0HBR0
Panel mounting thermostats and defrost controls for static units at low temperature
IR32Y: 2½digits, 12-24Vac/dc IR32Y0L000
IR32Y: 2½digits, 12-24Vac/dc, for remote control IR32Y0LBR0
Panel mounting thermostats and defrost controls for ventilated units at low temperature
IR32C: 2½digits, 12-24Vac/dc IR32C0L000
IR32C: 2½digits, 12-24Vac/dc IR32C0LBR0
IR32P: 2½digits (¹) IR32P0L000
IR32P: 2½digits, for remote control (¹) IR32P0LBR0
(¹) IR32P: must be used with S90RDPW200 (24-240 supply voltage, 3 relays, 4 Din modules casing) or
S90OEM4PWR (24-240 supply voltage, 4 relays, PC board) connected by S90CONN000/1/2.
Options
Alarm buzzer IR32***B**
IR receiver IR32***B**
IR32 serial output board IR32SER000
