9. CODES
Description Code
µC
2
single circuit, 2 compressors, panel mounting MCH2000000
µC
2
single circuit, 2 compressors, panel mounting (20 pcs. multiple package) MCH2000001
µC
2
single circuit, 2 compressors, DIN rail version MCH2000010
µC
2
single circuit, 2 compressors, DIN rail version (10 pcs. multiple package) MCH2000011
µC
2
expansion board for 2nd. circuit maximum 4 compressors MCH2000020
µC
2
expansion board for 2nd. circuit maximum 4 compressors (10 pcs. multiple package) MCH2000021
RS485 optional board for µC
2
panel version
MCH2004850
RS485 optional board for µC
2
DIN rail version
FCSER00000
Programming key for µC
2
PSOPZKEY00
ON/OFF fan card (only screw terminals) CONVONOFF0
PWM-0 to 10 V fan card (only screw terminals) CONV0/10A0
Fan card, faston terminals MCHRTF*0A0
Fan card, screw terminals
* depending on amperage (2= 2A, 4= 4A, 6= 6A, 8=8A)
MCHRTF*0B0
Temperature probes for regulation or condensation control
***depending on the length (015= 1.5 m, 030= 3 m, 060=6 m)
NTC***WP00
Pressure probes for condensing pressure control
** depending on the pressure (13= 150 PSI, 23= 75 PSI, 33= 500 PSI)
SPK*R*
Connectors kit for code MCH2000001 (multiple package 20 pcs) MCH2CON001
Connectors kit for code MCH2000001 (multiple package 10 pcs)
MCH2CON011
Connectors kit for code MCH2000001 (multiple package 10 pcs)
MCH2CON021
Minifit connectors kit + 1-meter length for code MCH20000**
MCHSMLCAB0
Minifit connectors kit + 2-meter length for code MCH20000**
MCHSMLCAB2
Minifit connectors kit + 3-meter length for code MCH20000** MCHSMLCAB3
Remote terminal for MCH20000** for panel installation MCH200TP0* MCH200TP0*
Remote terminal for MCH20000** for wall-mounting MCH200TW0* MCH200TW0*
Supervisor serial connection kit for remote terminal
MCH200TSV0
Table 9.a
