µchiller +0300053EN rel. 2.2 - 14.12.2021
Supervisor table
Index Size Ref. Type Min/Max R/W UoM Description
153 1 C000 INT 0 to 999 R/W h C000 - Maintenance hours threshold comp.1 circ.1 (x100)
154 1 C002 INT 0..2 R/W C002 - Comp. 1 circ. 1 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
155 1 C003 INT 0 to 999 R/W h C003 - Maintenance hours threshold comp. 2 circ. 1 (x100)
156 1 C005 INT 0..2 R/W C005 - Comp. 2 circ. 1 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
157 1 C006 INT 0 to 999 R/W h C006 - Maintenance hours comp. 1 circ. 2 (x100)
158 1 C008 INT 0..2 R/W C008 - Comp. 1 circ. 2 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
159 1 C009 INT 0 to 999 R/W h C009 - Maintenance hours threshold comp. 2 circ. 2 (x100)
160 1 C011 INT 0..2 R/W C011 - Comp. 2 circ. 2 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
162 1 C012 INT 30 to 999 R/W s C012 - Minimum compressor ON time
163 1 C013 INT 30 to 999 R/W s C013 - Minimum compressor OFF time
164 1 C014 INT 300 to 999 R/W s C014 - Minimum time between same compressor ON
165 1 C015 INT 10 to 999 R/W s C015 - Compressor load up time
166 1 C016 INT 5 to 999 R/W s C016 - Compressor load down time
167 1 S021 INT 0..23 R/W h Time band hours
168 1 C020 INT 5 to 999 R/W min C020 - Max circuit destabilisation time with one or more comp. OFF
169 1 C021 INT 0..1 R/W C021 - Circuit capacity distribution
(0 = balanced, 1 = grouped)
170 2 C022 REAL -99.9..99.9 R/W K/R C022 - Discharge temp. probe off set circ. 1
172 2 C023 REAL -99.9..99.9 R/W K/R C023 - Suction temp. probe off set circ. 1
174 2 C024 REAL -99.9..99.9 R/W K/R C024 - Discharge temp. probe off set circ. 2
176 2 C025 REAL -99.9..99.9 R/W K/R C025 - Suction temp. probe off set circ. 2
178 2 C026 REAL -99.9..99.9 R/W bar/psi C026 - Discharge pressure probe off set circ. 1
180 2 C027 REAL -99.9..99.9 R/W bar/psi C027 - Suction pressure probe off set circ. 1
182 2 C028 REAL -99.9..99.9 R/W K/R C028 - Condensing temp. probe off set circ. 1
184 2 C029 REAL -99.9..99.9 R/W K/R C029 - Evaporation temp. probe off set circ. 1
186 2 C030 REAL -99.9..99.9 R/W bar/psi C030 - Discharge pressure probe off set circ. 2
188 2 C031 REAL -99.9..99.9 R/W bar/psi C031 - Suction pressure probe off set circ. 2
190 2 C032 REAL -99.9..99.9 R/W K/R C032 - Cond. temp. probe off set circ. 2
192 2 C033 REAL -99.9..99.9 R/W K/R C033 - Evaporation temp. probe off set circ. 2
194 1 C037 INT 0..1 R/W C037 – Suction pressure: probe type (0 = 0-5V, 1 = 4-20mA)
195 2 C038 REAL -1.0..99.9 R/W bar/psi C038 - Suction pressure: minimum probe value
197 2 C039 REAL 0.0..99.9 R/W bar/psi C039 - Suction pressure: max probe value
199 1 C040 INT 0..1 R/W C040 – Discharge pressure: probe type (0 = 0-5V, 1 = 4-20mA)
200 2 C041 REAL -1.0..99.9 R/W bar/psi C041 - Discharge pressure: minimum probe value
202 2 C042 REAL 0.0..99.9 R/W bar/psi C042 - Discharge pressure: max probe value
204 1 C043 INT 0..1 R/W C043 - Discharge temp.: probe type (0 = NTC, 1 = NTC-HT)
206 1 C046 INT 1..2 R/W C046 - Number of circuits on the unit
207 1 C047 INT 0..1/3 R/W C047 - Type of compressors used
(0 = 1 ON / OFF, 1 = 2 ON / OFF, 2 = BLDC, 3 = BLDC + ON / OFF)
208 1 C048 INT 1..2 R/W C048 - Compressor rotation type (1 = FIFO, 2 = TIME)
209 1 S000 INT 0 to 999 R/W h S000 - Source pump 1 maintenance hour threshold (x100)
210 1 S002 INT 0..2 R/W S002 - Source pump 1 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
212 1 S022 INT 0..59 R/W min Time band minutes
214 1 S008 INT 0 to 999 R/W h S008 - Source fan 1 circ. 1 maintenance hours threshold (x100)
215 1 S010 INT 0..2 R/W S010 - ON/OFF source fan circ. 1 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
216 1 S011 INT 0..101 R/W % S011 - Inverter source fan circ. 1 manual mode (0 = AUTO, 1 = 0%, 2 = 1%, .. 101 =
100%)
217 1 S012 INT 0 to 999 R/W h S012 - Source fan 1 circ. 2 maintenance hours threshold (x100)
218 1 S014 INT 0..2 R/W S014 - ON/OFF source fan circ. 2 manual mode (0 = AUTO, 1 = OFF, 2 = ON)
219 1 S015 INT 0..101 R/W % S015 - Inverter source fan circ. 2 manual mode (0 = AUTO, 1 = 0%, 2 = 1%, .. 101 =
100%)
220 2 S016 REAL -999.9..999.9 R/W °C/°F S016 - Source fan temp. threshold for cold climates
222 2 S017 REAL 0..100 R/W % S017 - Minimum source fan speed for cold climates
224 2 S018 REAL 0..100 R/W % S018 - Source fan acceleration speed for cold climates
226 1 S019 INT 0..300 R/W s S019 - Source fan acceleration time for cold climates
227 2 REAL R/W % FC_PrwReq - Free cooling control ramp
229 2 Sprb REAL R °C/°F SPrb - Source outside air temperature;
231 2 S025 REAL 0..999.9 R/W °C/°F S025 - Source fan low noise set point in cooling
233 1 S026 INT 0 to 999 R/W s S026 - Comp. ON delay from source pump ON
234 1 S027 INT 0 to 999 R/W s S027 - Source pump OFF delay from comp. OFF
235 2 S028 REAL -999.9..999.9 R/W °C/°F S028 - Source fan set point in cooling
237 2 S029 REAL 0..99.9 R/W °C/°F S029 - Source fan set point in heating
241 2 S031 REAL 0..999.9 R/W °C/°F S031 - Source fan set point in cooling at start-up
243 1 S032 INT 0 to 999 R/W s S032 - Source fan start delay in cooling
246 2 S034 REAL 0..99.9 R/W K/R S034 - Source fan diff erential in cooling
248 2 S035 REAL 0..99.9 R/W K/R S035 - Source fan diff erential in heating
250 2 S036 REAL 0..100 R/W % S036 - Source fan inverter min speed
252 2 S037 REAL 0..100 R/W % S037 - Source fan inverter max speed
254 2 S039 REAL -99.9..99.9 R/W °C/°F S039 – Start defrost threshold
256 2 S040 REAL S039..99.9 R/W °C/°F S040 - Reset start defrost threshold
258 1 S041 INT 0 to 999 R/W min S041 - Start defrost delay
259 2 S042 REAL -999.9..999.9 R/W °C/°F S042 - End defrost threshold
261 1 S044 INT 0 to 999 R/W s S044 - Start defrost delay before 4-way valve is activated
262 1 S045 INT 0 to 999 R/W s S045 - End defrost delay after 4-way valve has been activated
263 1 S046 INT 0..99 R/W min S046 - Minimum defrost duration
264 1 S047 INT 0..99 R/W min S047 - Max defrost duration
