Supervisor table
Index Size Ref. Type Min/Max R/W UoM Description
100 2 rps1 REAL R rps PSD circuit 1: Actual rotor speed from the inverter
102 2 Mc1 REAL R A PSD circuit 1: Current motor current [A]
104 2 MP1 REAL R kW PSD circuit 1: Current motor power [kW]
106 2 Drt1 REAL R °C/°F PSD circuit 1: Current drive temperature [° C]
108 1 AlHs1_1 INT R PSD circuit 1: Last alarm log
109 1 AlHs2_1 INT R PSD circuit 1: Second-to-last alarm log
110 1 AlHs3_1 INT R PSD circuit 1: Third-to-last alarm log
111 1 AlHs4_1 INT R PSD circuit 1: Fourth-to-last alarm log
114 1 INT R MotTyp - BLDC circ. 1 Carel Database ID
115 1 INT R Envelope zone circuit 1
116 2 REAL R °C/°F EnvPnt_X1 - Envelope point coordinates circuit 1
118 2 REAL R °C/°F EnvPnt_Y1 - Envelope point coordinates circuit 1
120 2 REAL R °C/°F EnvPnt_X2 - Envelope point coordinates circuit 1
122 2 REAL R °C/°F EnvPnt_Y2 - Envelope point coordinates circuit 1
124 2 REAL R °C/°F EnvPnt_X3 - Envelope point coordinates circuit 1
126 2 REAL R °C/°F EnvPnt_Y3 - Envelope point coordinates circuit 1
128 2 REAL R °C/°F EnvPnt_X4 - Envelope point coordinates circuit 1
130 2 REAL R °C/°F EnvPnt_Y4 - Envelope point coordinates circuit 1
132 2 REAL R °C/°F EnvPnt_X5 - Envelope point coordinates circuit 1
134 2 REAL R °C/°F EnvPnt_Y5 - Envelope point coordinates circuit 1
136 2 REAL R °C/°F EnvPnt_X6 - Envelope point coordinates circuit 1
138 2 REAL R °C/°F EnvPnt_Y6 - Envelope point coordinates circuit 1
140 2 REAL R °C/°F EnvPnt_X7 - Envelope point coordinates circuit 1
142 2 REAL R °C/°F EnvPnt_Y7 - Envelope point coordinates circuit 1
144 2 REAL R °C/°F EnvPnt_X8 - Envelope point coordinates circuit 1
146 2 REAL R °C/°F EnvPnt_Y8 - Envelope point coordinates circuit 1
148 1 INT R Envelope zone circuit 2
149 2 REAL R °C/°F EnvPnt2_X1 - Envelope point coordinates circuit 2
151 2 REAL R °C/°F EnvPnt2_Y1 - Envelope point coordinates circuit 2
153 2 REAL R °C/°F EnvPnt2_X2 - Envelope point coordinates circuit 2
155 2 REAL R °C/°F EnvPnt2_Y2 - Envelope point coordinates circuit 2
157 2 REAL R °C/°F EnvPnt2_X3 - Envelope point coordinates circuit 2
159 2 REAL R °C/°F EnvPnt2_Y3 - Envelope point coordinates circuit 2
161 2 REAL R °C/°F EnvPnt2_X4 - Envelope point coordinates circuit 2
163 2 REAL R °C/°F EnvPnt2_Y4 - Envelope point coordinates circuit 2
165 2 REAL R °C/°F EnvPnt2_X5 - Envelope point coordinates circuit 2
167 2 REAL R °C/°F EnvPnt2_Y5 - Envelope point coordinates circuit 2
169 2 REAL R °C/°F EnvPnt2_X6 - Envelope point coordinates circuit 2
171 2 REAL R °C/°F EnvPnt2_Y6 - Envelope point coordinates circuit 2
173 2 REAL R °C/°F EnvPnt2_X7 - Envelope point coordinates circuit 2
175 2 REAL R °C/°F EnvPnt2_Y7 - Envelope point coordinates circuit 2
177 2 REAL R °C/°F EnvPnt2_X8 - Envelope point coordinates circuit 2
179 2 REAL R °C/°F EnvPnt2_Y8 - Envelope point coordinates circuit 2
181 2 rps2 REAL R rps PSD circuit 2: Actual rotor speed from the inverter
183 2 Mc2 REAL R A PSD circuit 2: Current motor current [A]
185 2 MP2 REAL R kW PSD circuit 2: Current motor power [kW]
187 2 Drt2 REAL R °C/°F PSD circuit 2: Current drive temperature [° C]
189 1 AlHs1_2 INT R PSD circuit 2: Last alarm log
190 1 AlHs2_2 INT R PSD circuit 2: Second-to-last alarm log
191 1 AlHs3_2 INT R PSD circuit 2: Third-to-last alarm log
192 1 AlHs4_2 INT R PSD circuit 2: Fourth-to-last alarm log
193 1 INT R MotTyp2 - BLDC circ. 2 Carel database ID
213 2 AFC2 REAL R °C/°F AFC2 - Condenser 2 frost protection temperature (S3 exp.)
217 2 AFC1 REAL R °C/°F AFC1 - Condenser 1 frost protection temperature (S3)
Tab. 7.d
