Adding a Modality and Configuring Modality Image Quality
2010-11-04 2G8647 4-3
Configuring Modalities Manually
The procedure used is determined by whether the modality uses
Presentation Look-Up Tables (PLUTs) or Transfer Function Tables
(TFTs).
1. Disable printing. From the Main Screen, select:
Utilities>Service>Printing enabled
This will change the state to Printing disabled.
2. Send an image from the modality to the Imager.
3. At the touch screen, select Configuration>Configure modality.
4. Select the modality.
5. Touch Select.
6. Select the General tab.
7. Touch Show last image parameters.
8. Is the value for IsPLUTPresent =, True or False?
Configuring
Modalities that use
PLUTs
1. From the Modality Configuration screen, touch:
• Close
• Close
2. Enable printing. Select Service>Printing disabled.
3. Select:
• Configuration
• Configure modality
• the modality
4. Touch Select.
5. Select the PLUT tab.
IMPORTANT: If you change a parameter value, you must select the check
box for Override modality? for that parameter.
6. Edit the parameters as necessary.
NOTE: It is recommended that you check with your modality or 6850 Imager
service person before making changes.
7. Touch Save.
8. Send another image from the modality.
True False
The modality uses PLUTs.
• Touch OK.
• Proceed to “Configuring
Modalities that use PLUTs”.
The modality uses TFTs.
• Touch OK.
• Proceed to “Configuring
Modalities that use TFT Sets and
Contrast Tables” on page 4-4.
